TL;DR
A maker has developed a new version of a voltmeter clock, enhancing its visual appeal and functionality. The project uses inexpensive panel meters and custom circuitry for smooth, continuous time display. This update makes the concept more accessible and visually appealing for electronics enthusiasts.
A hobbyist has unveiled a revised design for a voltmeter clock, featuring a cleaner aesthetic and smoother motion, making the project more accessible and visually appealing for electronics enthusiasts.
The new voltmeter clock uses three generic 90° panel voltmeters sourced from Amazon, disassembled and customized with printed decals for time display. The design incorporates a recessed front panel to hide the meters’ plastic flanges, achieved through CNC machining and precise wood bending techniques.
The clock’s circuit is built around an AVR128DB28 microcontroller, which controls the meters via digital output pins using a high-frequency pulse train, eliminating the need for complex digital-to-analog conversion. The software manages continuous motion of the hands by adjusting pulse duty cycles, providing a smooth transition between time units. The circuit is powered by a standard wall wart, with simple pushbuttons for setting the time.
Why It Matters
This project demonstrates how affordable components and straightforward electronics can create a visually compelling and functional clock, appealing to hobbyists and makers. It also offers an alternative to traditional digital clocks, emphasizing craftsmanship and customization, which could inspire similar DIY projects.
