TL;DR
A hobbyist has created a refined version of a voltmeter clock, emphasizing a cleaner design and smoother movement of hands. The project involves custom fabrication and simple electronics, showcasing accessible DIY innovation.
A hobbyist has unveiled a redesigned voltmeter clock featuring a cleaner aesthetic and continuous motion of its hands, emphasizing accessible DIY craftsmanship. The project involves repurposing inexpensive voltmeters and custom woodworking, highlighting an innovative approach to analog digital clocks.
The creator used three generic 90° panel voltmeters from Amazon, disassembled and customized with printed decals for the clock face. The design incorporates a new layout with 13 divisions for the hour dial and 61 divisions for minutes and seconds, enabling smooth, continuous movement rather than stepwise jumps.
The enclosure was crafted from resawn maple lumber, with a CNC-milled front and back, and a bent side wall achieved through internal notches and moisture bending, resulting in a seamless, polished appearance. The entire process combined woodworking techniques with precise measurements for a professional finish.
The electronic circuit powering the clock is simple and cost-effective, based on an AVR128DB28 microcontroller. It controls the meters via digital output pins, using a high-frequency pulse train to drive the analog needles without complex DACs. Time-setting is facilitated through small pushbuttons connected to input pins. The code, which is publicly available, manages duty cycles and timing to produce smooth, continuous hand movement.
Why It Matters
This project exemplifies accessible DIY innovation, combining affordable components with craftsmanship to produce a visually appealing and functional clock. It demonstrates how hobbyists can create unique, analog timepieces that blend electronics and woodworking, inspiring others in the maker community.
Such projects also highlight the potential for personalized, handcrafted devices that challenge conventional digital displays, appealing to enthusiasts interested in vintage aesthetics and custom engineering.
